| 42BYGHB |
![]() |
|
Price: $ 0.0
|
|
|
 General Specifications |
| Item | Specifications | | Step Angle | 1.8。 | | Step Angle Accuracy | ±5% (full step, no load) | | Resistance Accuracy | ±10% | | Inductance Accuracy | ±20% | | Temperature Rise | 80。C Max.(rated current,2 phase on) | | Ambient Temperature | -20。C~+50。C | | Insulation Resistance | 100MΩMin. ,500VDC | | Dielectric Strength | 500VAC for one minute | | Shaft Radial Play | 0.02Max. (450 g-load) | | Shaft Axial Play | 0.08Max. (450 g-load) | | Max. radial force | 28N (20mm from the flange) | | Max. axial force | 10N |
|
|
|
